Application: for the door of store restaurants, retail shop, sports center and station etc
Patent design and upgraded performance, good appearance and better quality.
Combine the advantage of cross flow and centrifugal air duct obtained the high air velocity at the same time.
High Efficient motor with thermal protector can operate continuously 5000h without failure. Higher air volume with superior performance.
Special Design of air deflection vane enables to adjust the air direction easily. Two speeds controlled by the remote control or Key Switch.
Silver Aluminum sand blast shell, 3D shape, newly aluminum bar air intake panel.
(Mounting height up to 4m) | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Model | Size | Frequency | Input Power High | Input Power Low | Air Speed High | Air Speed Low | Air Volume High | Air Volume Low | Noise High | Noise Low | Dimension | Weight |
FRX-4009-L/Y | 900 | 50 | 255 | 175 | 16 | 14 | 1700 | 1550 | 50 | 48 | 900x230x220 | 13.8 |
FRX-4010-L/Y | 1000 | 50 | 265 | 180 | 16 | 14 | 1800 | 1630 | 51 | 49 | 1000x230x220 | 14.5 |
FRX-4012-L/Y | 1200 | 50 | 355 | 240 | 16 | 14 | 2300 | 2090 | 53 | 50 | 1200x230x220 | 16.9 |
FRX-4015-L/Y | 1500 | 50 | 400 | 310 | 16 | 14 | 2900 | 2615 | 54 | 51 | 1500x230x220 | 20.5 |
FRX-4018-L/Y | 1800 | 50 | 510 | 420 | 16 | 14 | 3500 | 3150 | 56 | 53 | 1800x230x220 | 25.4 |
FRX-4020-L/Y | 2000 | 50 | 530 | 430 | 16 | 14 | 3600 | 3265 | 57 | 54 | 2000x230x220 | 26.5 |
